How to Install Let’s Encrypt SSL on Ubuntu 18.04 & 16.04, 14.04 LTS

Table of Contents[Hide][Show]

This guide covers the easy way to install Let’s Encrypt SSL on Ubuntu Server with NGINX. Let’s Encrypt is one of the newest Certificate Authority (CA). It is the easiest way to get TLS/SSL certificates. The entire process of obtaining and installing an SSL certificate is fully automated when it comes to Apache webserver. The installation of LetsEncrypt on any other web server can be done manually.

In this guide, I will show you how to obtain and install Let’s Encrypt SSL certificate and use it with Nginx web server on Ubuntu 14.04, 16.04 or 18.04 and the web application that I will be using is WordPress. At the end of this guide, I will show you how you can automatically renew your SSL certificate.

7 Easy Steps to Install Let’s Encrypt SSL on Ubuntu 18.04 & 16.04, 14.04 LTS

Here are the 7 easy steps that will help you to install Let’s Encrypt SSL on Ubuntu. But before you start, make sure to update your server’s software packages by running the following command.

sudo apt-get update && sudo apt-get upgrade

Step 1 – Install Let’s Encrypt SSL Client

Install the Git package:

Git packages can be installed by running the command below::

sudo apt-get install git

Once you install the Git Package, download a clone of Let’s Encrypt from official GitHub repository. As we know that, for third-party packages, /opt is a common installation directory. So we need to install Let’s Encrypt SSL to /opt/letsencrypt directory.

sudo git clone https://github.com/letsencrypt/letsencrypt /opt/letsencrypt

Now, you will have a copy of Let’s Encrypt repository in the /opt/letsencrypt directory.

Position your bash prompt in your new /opt/letsencrypt directory.

cd /opt/letsencrypt

Step 2 – Obtaining a Certificate

There are numerous ways of obtaining an SSL certificate. There are various plugins that help you to obtain an SSL certificate. You can configure it for the use on your web server.

Well, Let’s Encrypt performs a series of challenges to automatically verify the domain and install Let’s Encrypt SSL on Ubuntu for the particular domain.

The Certificate Authority (CA) uses those challenges to verify the authenticity of your domain and website. Once your website is validated, the Certificate Authority (CA) will issue an SSL certificate for your website.

Now run Let’s Encrypt with the --standalone parameter. For each additional domain that requires a certificate, add -d example.com at the end of the command. e.g.,

sudo -H ./letsencrypt-auto certonly --standalone -d example.com -d www.example.com

Replace example.com with your own domain name.

At the prompt, specify an administrative email address that will help you regain the control lost certificate or key recovery.

Once you enter the correct email address, Press TAB followed by ENTER or RETURN to save.

Now, agree to the Subscriber Agreement by Let’s Encrypt.

If all goes well, you will see an output message that goes something this:

IMPORTANT NOTES:

- If you lose your account credentials, you can recover them through

e-mails sent to admin@example.com.

- Congratulations! Your certificate and chain have been saved at
/etc/letsencrypt/live/example.com/fullchain.pem. Your
cert will expire on 2016-03-12. To obtain a new version of the
certificate in the future, simply run Let's Encrypt again.
- Your account credentials have been saved in your Let's Encrypt
configuration directory at /etc/letsencrypt. You should make a
secure backup of this folder now. This configuration directory will
also contain certificates and private keys obtained by Let's
Encrypt, so making regular backups of this folder is ideal.
- If you like Let's Encrypt, please consider supporting our work by:

Donating to ISRG / Let's Encrypt:   https://letsencrypt.org/donate
Donating to EFF:                    https://eff.org/donate-le

Here, you should keep a note of the path and expiration date of your certificate.

Step 3 – Let’s Encrypt Directory Structure

It is important that you are aware of the location of the certificate files that you just created. Later, you can use them while configuring your web server. So let’s explore the directory structure.

sudo ls /etc/letsencrypt/live

For every domain name, that you specified in Step I, there is an own directory. You can check the directory one by one. In this example, I am going to explore the example.com directory.

sudo ls /etc/letsencrypt/live/example.com

Output:

Each key (.pem) file in this directory serves a different purpose:

cert.pem: Certificate of your domain

chain.pem: Chain certificate of Let’s Encrypt.

fullchain.pem: It is a combination of cert.pem and chain.pem

privkey.pem: Your certificate’s private key (never ever share this key with anyone)

For good measure, you need to check the file status of fullchain.pem:

sudo stat /etc/letsencrypt/live/example.com/fullchain.pem

Output:

File: ‘live/example.com/cert.pem’ -> ‘../../archive/example.com/cert1.pem’

You can notice how this file points to a different file. Actually, they are the symbolic links to the actual certificate files located in
/etc/letsencrypt/example.com directory.

Step 4 – Generate Strong Diffie-Hellman Group

To further improve the security, generate a strong Diffie-Hellman group. To generate a 2048-bit group, use the following command:

sudo openssl dhparam -out /etc/ssl/certs/dhparam.pem 2048

Generation of the Diffie-Hellman group might take a couple of minutes but when it’s generated you will have a strong Diffie-Hellman group at /etc/ssl/certs/dhparam.pem,/code>.

Step 5 – Configure TLS/SSL on Web Server (Nginx)

Now we have that certificate that we will require for Nginx web server. So now we can configure Nginx webserver to start using SSL.

Now we need to edit the Nginx configuration that contains our server block at /etc/nginx/sites-available/example.com in our case.

sudo vim /etc/nginx/sites-available/example.com

Now find the server block and make changes and it should look like something this:

server {
  listen 80;
  listen [::]:80;
  server_name example.com www.example.com *.example.com;
  return 301 https://www.example.com$request_uri;
}

Once you configure the server block on port 80, then configure this server block on port 443 with SSL enabled. And it should look like something this:

# HTTPS serve
server {
listen 443;
server_name www.example.com example.com;
root /var/www/example.com/public_html;
index index.php index.html index.htm;
access_log /var/log/nginx/example.access.log;
error_log /var/log/nginx/example.error error;

ssl on;
ssl_certificate /etc/letsencrypt/live/example.com/fullchain.pem;
ssl_certificate_key /etc/letsencrypt/live/example.com/privkey.pem;
ssl_session_timeout 5m;
ssl_protocols TLSv1 TLSv1.1 TLSv1.2;
ssl_ciphers 'EECDH+AESGCM:EDH+AESGCM:AES256+EECDH:AES256+EDH';
ssl_prefer_server_ciphers on;

location / {

# First attempt to serve request as file, then
# as directory, then fall back to displaying a 404.
try_files $uri $uri/ /index.php?$args;
# Uncomment to enable naxsi on this location
# include /etc/nginx/naxsi.rules
}

# pass the PHP scripts to FastCGI server listening on 127.0.0.1:9000

location ~ .php$ {
  fastcgi_split_path_info ^(.+.php)(/.+)$;
  # NOTE: You should have "cgi.fix_pathinfo = 0;" in php.ini
   # With php7.0-fpm: fastcgi_pass unix:/var/run/php/php7.0-fpm.sock; fastcgi_index index.php; include fastcgi_params; fastcgi_param  SCRIPT_FILENAME  $document_root$fastcgi_script_name;
 }
}

Now let’s understand some of the important things about our configuration:

SSL Protocol

We need to disable SSL v2 as it is insecure. We also disabled SSLv3, as TLS 1.0 suffers a downgrade attack.

So we used the following ssl_protocol:

ssl_protocols TLSv1 TLSv1.1 TLSv1.2;

Cipher Suite

A cipher suite is nothing but the collection of symmetric and asymmetric encryption algorithm. The cipher suite that we used:

ssl_ciphers 'EECDH+AESGCM:EDH+AESGCM:AES256+EECDH:AES256+EDH';

If you are looking for cipher suite for backwards compatibility for IE6/WinXP, here is a recommended cipher suite:

ssl_ciphers "EECDH+AESGCM:EDH+AESGCM:ECDHE-RSA-AES128-GCM-SHA256:AES256+EECDH:DHE-RSA-AES128-GCM-SHA256:AES256+EDH:ECDHE-RSA-AES256-GCM-SHA384:DHE-RSA-AES256-GCM-SHA384:ECDHE-RSA-AES256-SHA384:ECDHE-RSA-AES128-SHA256:ECDHE-RSA-AES256-SHA:ECDHE-RSA-AES128-SHA:DHE-RSA-AES256-SHA256:DHE-RSA-AES128-SHA256:DHE-RSA-AES256-SHA:DHE-RSA-AES128-SHA:ECDHE-RSA-DES-CBC3-SHA:EDH-RSA-DES-CBC3-SHA:AES256-GCM-SHA384:AES128-GCM-SHA256:AES256-SHA256:AES128-SHA256:AES256-SHA:AES128-SHA:DES-CBC3-SHA:HIGH:!aNULL:!eNULL:!EXPORT:!DES:!MD5:!PSK:!RC4";

So here is our overall configuration for website example.com

server {
    listen 80;
    listen [::]:80;
    server_name example.com www.example.com *.example.com;
    return 301 https://www.example.com$request_uri;
  }
  HTTPS server
  server {
    listen 443;
    listen [::]:443 ssl;
    server_name example.com www.example.com *.example.com;
    root /var/www/html/example.com/public_html;
    index index.php;
    access_log /var/log/nginx/example.access.log;
    error_log /var/log/nginx/example.error error;
  location ~ /.well-known {
              allow all;
    }
  #Leverage browser caching
    location ~*  .(jpg|jpeg|png|gif|ico|css|js)$ {
          expires 365d;
      }
      location ~*  .(pdf)$ {
          expires 30d;
      }
 ssl on;
 ssl_certificate /etc/letsencrypt/live/example.com/fullchain.pem;
 ssl_certificate_key /etc/letsencrypt/live/example.com/privkey.pem;
 ssl_session_timeout 1d;
 ssl_protocols TLSv1 TLSv1.1 TLSv1.2;
 ssl_ciphers 'EECDH+AESGCM:EDH+AESGCM:AES256+EECDH:AES256+EDH';
 ssl_ciphers 'EECDH+AESGCM:EDH+AESGCM:AES256+EECDH:AES256+EDH:ECDHE-RSA-AES128-GCM-SHA384:ECDHE-RSA-AES128-GCM-SHA256:ECDHE-RSA-AES128-GCM-SHA128:DHE-RSA-AES128-GCM-SHA384:DHE-RSA-AES128-GCM-SHA256:DHE-RSA-AES128-GCM-SHA128:ECDHE-RSA-AES128-SHA384:ECDHE-RSA-AES128-SHA128:ECDHE-RSA-AES128-SHA:ECDHE-RSA-AES128-SHA:DHE-RSA-AES128-SHA128:DHE-RSA-AES128-SHA128:DHE-RSA-AES128-SHA:DHE-RSA-AES128-SHA:ECDHE-RSA-DES-CBC3-SHA:EDH-RSA-DES-CBC3-SHA:AES128-GCM-SHA384:AES128-GCM-SHA128:AES128-SHA128:AES128-SHA128:AES128-SHA:AES128-SHA:DES-CBC3-SHA:HIGH:!aNULL:!eNULL:!EXPORT:!DES:!MD5:!PSK:!RC4';
 ssl_prefer_server_ciphers on;
 location / {
     # First attempt to serve request as file, then
     # as directory, then fall back to displaying a 404.
     try_files $uri $uri/ /index.php?$args;
     # Uncomment to enable naxsi on this location
     # include /etc/nginx/naxsi.rules
   }
 pass the PHP scripts to FastCGI server listening on 127.0.0.1:9000
 location ~ .php$ {
   fastcgi_split_path_info ^(.+.php)(/.+)$;
   # NOTE: You should have "cgi.fix_pathinfo = 0;" in php.ini
    # With php7.0-fpm: fastcgi_pass unix:/var/run/php/php7.0-fpm.sock; fastcgi_index index.php; include fastcgi_params; fastcgi_param  SCRIPT_FILENAME  $document_root$fastcgi_script_name;
  }
}

Step 6 – Maintenance & Renewal

Return your Bash prompt to the /opt/letsencrypt directory:

cd /opt/letsencrypt

Now execute the same command that was used in Step 2 during obtaining a certificate, but we need to add an additional --renew-by-default parameter for auto-renewal:

sudo -H ./letsencrypt-auto certonly --standalone --renew-by-default -d example.com -d www.example.com

Shortly you see a confirmation similar to the one below should:

IMPORTANT NOTES:
- Congratulations! Your certificate and chain have been saved at
/etc/letsencrypt/live/example.com/fullchain.pem. Your
cert will expire on 2016-03-12. To obtain a new version of the
certificate in the future, simply run Let's Encrypt again.
- If you like Let's Encrypt, please consider supporting our work by:
Donating to ISRG / Let's Encrypt:   https://letsencrypt.org/donate
Donating to EFF:                    https://eff.org/donate-le

Automate SSL Certificate Renewal (Optional)

Automating your certificate renewal will prevent your certificate from expiring in case you forget to renew.

echo '@monthly root /opt/letsencrypt/letsencrypt-auto certonly --standalone --renew-by-default -d example.com -d www.example.com >> /var/log/letsencrypt/letsencrypt-auto-update.log' | sudo tee --append /etc/crontab

@monthly: for simplicity, this command is executed at midnight on the first day of every month

root: run the command as the root user

/opt/letsencrypt/letsencrypt-auto certonly –standalone –renew-by-default -d example.com -d www.example.com: It’s a Let’s Encrypt-auto renewal command. You can add -d example.com for each domain name that you need to renew.

>> /var/log/letsencrypt/letsencrypt-auto-update.log: This file keeps the record of standard output and standard error.

tee –append /etc/crontab: It saves the new cron job to the /etc/crontab file.

Step 7 – Update Let’s Encrypt

To update LetsEncrypt, return your Bash prompt to the /opt/letsencrypt directory by running the following command:

cd /opt/letsencrypt

Now update Let’s Encrypt by running the following command:

sudo git pull

If you want this step to be automated, you can set auto-update by running the following command:

echo '@weekly root cd /opt/letsencrypt && git pull >> /var/log/letsencrypt/letsencrypt-auto-update.log' | sudo tee --append /etc/crontab

That’s it! You are done installing the Let’s Encrypt SSL Certificate. Now you have free Let’s Encrypt TLS/SSL certificate running on your web server that securely serves HTTPS content.

You may also like:

Hope you will like this How to Install Let’s Encrypt SSL Installation Guide. If you face any difficulty while Let’s Encrypt SSL installation, feel free to ask me.

Do share your feedback in the comment section below.
